2000G-WDL Wind Grid Tie Inverter DC Input

  • Number:2000G-WDL
  • Specif:2000W 45-90V dc Input
  • Size:460*196*88mm
  • Category:Wind Grid Tie Inverter
  • Gotline:18930085899
  • Details

  • Contact

Features:

●  Easy installation, this inverter can be paralleled on AC side
●  This inverter Can be integrated with internal limit function
●  Battery discharge power mode enabled, which can auto regulate depth of discharge ofthe battery bank
●  Zigbee wireless communication extended interface, enable inverter power production data collect by energy collect device(ECD)
●  Nice LCD display various parameters including input voltage, output power,temperature,power curve,output sine waveform etc

Model NO:\TEG-

1000G-WAL

1000G-WDL

2000G-WAL

2000G-WDL

Normal AC Output Power

950W

1900W

Maximum AC Output Power

1000W

2000W

3 phase AC Voltage Range(Input)

22V-65V / 45V-90V

-

45V-90V

-

DC Voltage Range (Input)

-

22V-65V / 45V-90V

-

45V-90V

Output Current Waveform

Pure Sine Wave

Power Factor

0.95

Output AC Voltage Range

95V~140V / 185V~265V(Auto Detect)

185V~265V

Frequency

46~65Hz

Anti-island Protection

Yes

Over Current Protection

Yes

Reverse Polarity Protection

Fuse

Dispaly

LCD

Standby Power

1.2W

1.2W

1.5W

1.5W

Working temperature

-20℃~ +50℃

Overall dimension(mm)

350×196×88

350×196×88

460×196×88

460×196×88

Net weight

5.1kg

4.9kg

7.5kg

7.3kg


Order:2000G-WDL Wind Grid Tie Inverter DC Input
